Fully compatible with:

-  USB 3.2 SuperSpeed Plus: Universal Serial Bus 3.2 Specification, Revision 1.1

Supports data rates:

-  USB 3.2 SuperSpeed Plus 10 Gbps (Gen 2) and 5 Gbps (Gen 1)

Supports all USB 3.2 power management modes

Spread spectrum clock (SSC) and data scrambling to minimize EMI

APB and I2C interfaces to access the internal registers for different applications

Multiple loopback and compliance test modes

Built-in BIST pattern generator and checker with programmable modes for stand-alone tests

On-chip Eye Opening Monitor (EOM) to measure the eye diagram at the RX side

Adaptive and configurable RX continuous time linear equalizer (CTLE) and decision feedback equalizer (DFE)

Programmable TX feed-forward equalization (FFE)

8b/10b and 128b/132b encoding and decoding implemented in hardware

Supports LFPS generation and detection

IEEE standards 1149.1 and 1149.6 (JTAG) boundary scan for internal visibility and control

Supports a wide range of reference clocks: 12/19.2/20/24/25/26/27/30/38.4/40/48/50/52/54/60/100/200 MHz
