Hantro VC9800E

Home IP Portfolio Hantro^® VPU IP Hantro VC9800E

High Number of Streams Encoder For Data Center

Hantro VC9800E enables up to 256 streams encoding with high video quality single-core solution, or multi-core solution, supporting AV1, HEVC, H.264, VP9 video formats and JPEG.

VeriSilicon's Hantro VC9800E is based on silicon-proven VeriSilicon Hantro technology and target to demand the high quality, high throughput, low bandwidth data centers to address the video transcoding, AI server, desktop virtualization even cloud gaming applications. Hantro VC9800E provides semiconductor manufacturers a minimum risk solution for integrating high-performance video capability into their chips.

Hantro VC9800E

All the help you need

VeriSilicon operates globally and we are happy to meet you at any time to discuss your order demand for Hantro VC9800E.
Please feel free to contact us and submit your request online, or reach out to your nearest VeriSilicon sales office for making an order or appointment, or meet us at the next industry event.

Video Formats

Unified architecture supports multiple formats

AV1 main profle 8/10bit

HEVC main10, main, and main still profiles

H.264 Baseline, main and High, High10

VP9 profile 0 and profile 2 (10-bit)

JPEG

High Performance and Throughput

Up to 8K@30fps/16x1080P@30fps performance with a single-core

Up to 8K@120fps/64x1080P@30fps with multiple cores

High BUS latency tolerance without performance impact

Up to 256 streams in a single device

Maximally offloads the system CPU

Leading in PPA/Die Area for high performance solution

High Encoding Quality

Leading PSNR BDR data in data center video processors

New SCC(Screen Content Coding) Encoding tools for improving artificial sequences(Like Gaming) encoding quality and efficiency

Enhanced large motion sequences encoding mechanism to improve encoding quality for high speed scenes

Visual quality optimization for gaming video

User Controlled Intelligent encoding capability with AI by FLEXA-AI API

Features for Different Application Requirements

Based on frame level switching of virtual machine tasks, providing ultra-low latency task scheduling capabilities for cloud computing applications

Inline preprocessing features and OSD blending

DDR efficiency and bandwidth saving

Sub-picture Low-latency encoding

Security and DRM support

Flexible HW Configuration

HW configuration can be done for most video formats

Typical 1-4 cores or more in a device

Good balance between PPA and video quality for different targets

Configurable on quality level, feature set, and different performance

Controllable balance between performance and quality

Bandwidth saving by reference frame & input frame compression

API support

OpenMax-IL

FFmpeg avcodec Plug-in

VAAPI

Hantro Video Private ctrlSW API

V4L2 API
