MIPI Alliance Specification compliant with D-PHY Version 3.0

MIPI Alliance Specification compliant with C-PHY Version 2.1

MIPI Alliance Standard compliant with Display Serial Interface 2 (DSI-2) Version 2.2

Supports D-PHY de-skew, alternative calibration

Supports configurable 4 ppc or 1 ppc in DPI interface, and both video and command modes

Command mode supports 16/18/24/30/36-bit RGB using DPI interface as 1 pixel per cycle or 4 pixels per cycle

Supports arbitrary command packet size which can be divided by total pixels per frame

Video mode supports all pixel formats (up to 48-bit DPI data width) in DSI-2 v2.2

Supports APB3 control register with shadow configuration mechanism

Supports command among video mode and enhanced Display Pixel Interface

Supports BIST mode (color bar), timeout error detection, and error report from peripheral

Interfaces with optional MIPI D-PHY or C-PHY following PHY Protocol Interface (PPI)

Supports D-PHY: 8-bit, 16-bit, or 32-bit PPI (programmable)

Supports C-PHY: 16-bit, 32-bit, or 64-bit PPI (programmable)

Supports up to MIPI D-PHY TX 4 data lanes and C-PHY TX 3trios

Supports D-PHY high-speed and low-power operation, C-PHY high-speed and low-power operation

Supports programmable scrambling

Supports programmable polarity for enhanced DPI signals

Configurable SRAM size
