Compatible with HDMI 2.0/1.4 TX PHY operation

Supports up to 1080p at 120 Hz and 4K x 2K at 60 Hz HDTV display resolutions

Supports 3-D video formats

Supports deep color modes: 30, 36, and 48 bits

Supports link controller interface with 30 bits, 60 bits, or 120 bits data access

50% duty-cycle output clock

I2C interface for configuration

Supports RX sensing and Hot Plug Detect (HPD)

Source termination impedance is auto-calibrated

Built-in Self-Test (BIST) is integrated inside

Support TMDS clock range from 40MHz to 600MHz
