Enabling High Performance Real-Time Image Processing
As an industry-leading full camera ISP IP, VeriSilicon's Vivante Image Signal Processor (ISP) features sophisticated pixel processing for wearable device, smart home, video surveillance and automotive applications. The ISP8000 series is one of the most efficient RTL based implementations for high performance real-time image processing. It features low gate count per chip area, low power consumption, as well as higher throughput while at the same time lower memory requirements. Based on silicon-proven design, the ISP provides a minimal risk solution for integrating high performance image signal processor into silicon products.
Baseline ISP Features
Support DVP Input Interface
Support 8-16 Bit Bayer RAW and ITU-R BT.601 & 656 Video Interface
Test Pattern Generator (TPG)
Black Level Measurement and Compensation (BLS)
Sensor Linear Correction
Defect Pixel Cluster Correction (DPCC)
Green Equalization
Lens Shading Correction (De-Vignetting)
Digital Gain
2 Stage Adaptive Noise Filter
Enhanced Color Interpolation (Demosaic)
Chromatic Aberration Correction (CAC)
Baseline ISP Features
Color Correction Matrix (CCM)
Gamma Correction
Auto Focus Measurement (AF)
Auto White Balancing (AWB)
Auto Exposure Measurement (AE)
Histogram Calculation
Anti-flicker
Cropping of the Output Picture
Color Processing (Contrast, Saturation, Brightness, Hue) (CPROC)
Sharpening/Blurring Filter
Flash Light Control &Mechanical Shutter Control
Color Space Conversion (CSM)
Advanced Features
Wide Dynamic Range Tone Mapping (WDR)
Multi-exposure HDR (Native/build in HDR, Compand output)
Multi-exposure HDR (DOL/Stagger, Stagger output)
Advanced 2DNR to Remove Spatial Noise
- ISP8000 Support Advanced 2DNR-XL
3DNR to Remove Temporal Noise
- ISP8000 Support Advanced 3DNR-XL
Enhanced Chroma Noise Reduction (CNR)
Video Stabilization Support (VSM)
Image Signal Processor Advantages
Ease of Integration, Very Low CPU loading, typical below 1 MIPS per frame / second
Ultra short capture delay (hard wired, separate preview & proc. path)
RAW data can be stored in memory for pre/post processing
Resolution scalable architecture (2MP, 4MP, 5MP, 8MP, 12MP, 18MP, 24MP, 36MP and up to 64MP)
Silicon proven design
High throughput rate up to 800 mega pixel/second (e.g. 8MP at 100fps)
FPGA platform available for pre-silicon software development
Optional Added-On
Dual-ISP with Shared Memory Pool (SMP)
Multi-Context management to support two sensors within one ISP Core (MCM)
Tile mechanism for 8K resolution
RGB-IR 4x4 pattern
Configurable 10/12bit YUV output
RCCB and RCCC type sensor
PDAF Sensor
Function safety machanism, ASIL-B, ISO26262 certification
Specific Output interface and Channels for ISP8000L/ISP8000
Main Digital Zoom (Main-Path Scaling) & Continuous Resize Support (MP)
Self-Digital Zoom, output path-1(SP-1)
Self-Digital Zoom, output path-2(SP-2)
Format Conversion Between YCBCr 4:2:2, 4:2:0, RGB Formats, Planar and Semi-Planar Storage Format for YCBCr
DMA Read Path to Feed Pipeline with Data from Memory
FLEXA API based stream interface to external blocks
