High Number of Streams Decoder For Data Center

VeriSilicon's Hantro VC9800D enables up to 256 streams decoding with robustness, high throughput single-core solution, or multi-core solution, supporting VVC, AV1, HEVC, H.264, AVS3, AVS2, VP9 video formats, JPEG, and legacy formats.

VeriSilicon's Hantro is based on silicon-proven VeriSilicon Hantro technology and target to demand the high number steams, high throughput, low bandwidth data centers to address the video transcoding, AI server, desktop virtualization even cloud gaming applications.

Hantro VC9800D provides semiconductor manufacturers a minimum risk solution for integrating high-performance video capability into their chips.

Hantro VC9800D

All the help you need

VeriSilicon operates globally and we are happy to meet you at any time to discuss your order demand for Hantro VC9800D.
Please feel free to contact us and submit your request online, or reach out to your nearest VeriSilicon sales office for making an order or appointment, or meet us at the next industry event.

Video Formats

Unified architecture supports multiple formats

VVC Main Profile 8/10bit

AV1 main profile

HEVC main10, main, and main still profiles

H.264 up to constraint high10 profile

VP9 profile 0 and profile 2 (10-bit)

AVS3.0 main-10 bit profile

AVS2.0 main/main10 profile

JPEG (Include Progressive JPEG)

Legacy formats: MPEG4, MPEG2, MPEG1, VC-1, H.263, VP8, VP7, VP6, RV10, RV9, RV8, AVS, AVS+, Sorenson, DIVX3/4/5/6, WebP

High Performance and Throughput

Up to 8K@30fps/16x1080P@30fps performance with a single-core

Up to 8K@120fps/64x1080P@30fps with multiple cores

High BUS latency tolerance without mainstream decoding format performance impact

Up to 256 streams in a single device

Maximally offloads the system CPU

Leading in PPA/Die Area for high performance solution

Versatile Inline Post Processing

Bandwidth efficient solution by inline processing

Multiple post processing outputs

High quality resize and programmable scaling kernel

RGB formats for AI models

Compatible VSI GPU rendering formats for high working efficiency with VSI GPU

Rich post-processing capability, such as blending, image stitch, color remapping, rotation, flip, etc

Features for Different Application Requirements

Based on frame level switching of virtual machine tasks, providing ultra-low latency task scheduling capabilities for cloud computing applications

Error concealment and robustness

Independent multiple Post-processing channel for Video transcoding

Support compatible AI input NCHW(Planar)/NHWC(Packed) output to best fit AI applications

Matching OpenCV resize precision for AI applications

Normalization for AI pre-processing

DDR efficiency and bandwidth saving

Low-latency decoding

Security and DRM support

Flexible HW Configuration

HW configuration can be done for most video formats

Typical 1-4 cores or more in a device

PP different channels can have different features and restriction

Data caching and burst shaping for good DDR efficiency in specific system

Bandwidth saving by reference frame & output frame compression

Optional MMU, encryption

API support

OpenMax-IL

FFmpeg avcodec Plug-in

VAAPI

Hantro Video Private ctrlSW API

V4L2 API
